Hard magnetic coating on the tip side (coercivity between 0.75 and 300 Oe, remanence magnetization between 80 and 300 emu/cm³)
Effective magnetic moment between 2.5 and 13 emu
Metallic electrical conductivity
Lowest possible guaranteed tip radius of curvature down to < 15 nm
Highest possible magnetic resolution better than 25 nm
Al coating on detector side of AFM cantilever enhancing the reflectivity of the laser beam by a factor of about 2.5
| Product# | Description | Unit | Price | Qty / Quote |
|---|---|---|---|---|
| PPP-MFMR-10 | k: 2.8N/m; f: 75kHz; Hard Magnetic, Medium Momentum MFM AFM Probe; Coating: Magnetic; AFM tip shape: Standard; 10/box  |
each | $779.95 | |
| PPP-MFMR-20 | k: 2.8N/m; f: 75kHz; Hard Magnetic, Medium Momentum MFM AFM Probe; Coating: Magnetic; AFM tip shape: Standard; 20/box |
each | $1,396.50 | |
| PPP-MFMR-50 | k: 2.8N/m; f: 75kHz; Hard Magnetic, Medium Momentum MFM AFM Probe; Coating: Magnetic; AFM tip shape: Standard; 50/box |
each | $3,078.95 | |
| PPP-MFMR-W | k: 2.8N/m; f: 75kHz; Hard Magnetic, Medium Momentum MFM AFM Probe; Coating: Magnetic; AFM tip shape: Standard; 380/box |
each | $15,742.45 | |
| PPP-LC-MFMR-10 | k: 2.8N/m; f: 75kHz; Soft Magnetic, Medium Momentum MFM AFM Probe; Coating: Magnetic; AFM tip shape: Standard; 10/box |
each | $779.95 | |
| PPP-LC-MFMR-20 | k: 2.8N/m; f: 75kHz; Soft Magnetic, Medium Momentum MFM AFM Probe; Coating: Magnetic; AFM tip shape: Standard; 20/box |
each | $1,396.50 | |
| PPP-LC-MFMR-50 | k: 2.8N/m; f: 75kHz; Soft Magnetic, Medium Momentum MFM AFM Probe; Coating: Magnetic; AFM tip shape: Standard; 50/box |
each | $3,078.95 | |
| PPP-LM-MFMR-10 | k: 2.8N/m; f: 75kHz; Hard Magnetic, Low Momentum MFM AFM Probe; Coating: Magnetic; AFM tip shape: Standard; 10/box |
each | $779.95 | |
| PPP-LM-MFMR-20 | k: 2.8N/m; f: 75kHz; Hard Magnetic, Low Momentum MFM AFM Probe; Coating: Magnetic; AFM tip shape: Standard; 20/box |
each | $1,396.50 | |
| PPP-LM-MFMR-50 | k: 2.8N/m; f: 75kHz; Hard Magnetic, Low Momentum MFM AFM Probe; Coating: Magnetic; AFM tip shape: Standard; 50/box |
each | $3,078.95 | |
| PPP-QLC-MFMR-10 | k: 2.8N/m; f: 75kHz; Soft Magnetic, Medium Momentum MFM AFM Probe with a High Mechanical Q-Factor; Coating: Magnetic; AFM tip shape: Standard; 10/box |
each | $1,337.60 | |
| SSS-MFMR-10 | k: 2.8N/m; f: 75kHz; SuperSharp, Hard Magnetic, Low Momentum MFM AFM Probe; Coating: Magnetic; AFM tip shape: Supersharp; 10/box |
each | $1,337.60 | |
| SSS-MFMR-20 | k: 2.8N/m; f: 75kHz; SuperSharp, Hard Magnetic, Low Momentum MFM AFM Probe; Coating: Magnetic; AFM tip shape: Supersharp; 20/box |
each | $2,393.05 | |
| SSS-MFMR-50 | k: 2.8N/m; f: 75kHz; SuperSharp, Hard Magnetic, Low Momentum MFM AFM Probe; Coating: Magnetic; AFM tip shape: Supersharp; 50/box |
each | $5,278.20 | |
| SSS-QMFMR-10 | k: 2.8N/m; f: 75kHz; SuperSharp, Hard Magnetic, Low Momentum MFM AFM Probe with a High Mechanical Q-Factor; Coating: Magnetic; AFM tip shape: Supersharp; 10/box |
each | $1,505.75 |
