AFM accessories-Appnano-silion prober
- AppNano develops, manufactures, and supplies various nanostructures including standard and specialized SPM probes that are compatible with all major AFM equipment in the market for most applications
- We leverage our extensive experience in nanofabrication technology and research in SPM probes to supply the highest quality probes
- Our in-house clean room facility combined with our state-of-the-art characterization tools enables rapid prototyping, adaptability, and versatility in designing and developing custom products
- Major research programs are continuously underway both in-house and with external collaborators to develop high performance probes for advanced applications
| Product# | Description | Unit | Price | Qty / Quote |
|---|---|---|---|---|
| ACCESS-C-10 | k:0.3N/m;f:16kHz;Tip-view-Contact mode, Uncoated, Si probe;10/box |
each | $418.00 | |
| ACCESS-EFM-10 | k:2.7N/m;f:60kHz; PtIr coated- Tip view- Force modulation EFM, Si probe;10/box |
each | $534.00 | |
| ACCESS-FM-GG-10 | k:2.7N/m;f:60kHz; Au coated- Tip view- Tapping?/Non-contact EFM, Si probe;10/box  |
each | $534.00 | |
| HYDRA2R-100NGG-10 | k:0.011N/m;f:21kHz;Contact mode in liquid, Au on both sides- Si nitride cantilever with Si tip;10/box |
each | $375.00 | |
| HYDRA2R-100NGG-TL-10 | k:0.011N/m;f:26kHz;Tipless- Custom applications in air, Au coated, Si nitride cantilever;10/box |
each | $375.00 | |
| ACL-10 | k:58N/m;f:190.0kHz;TappingTM/Non-contact mode in air, Long lever-Uncoated, Si probe;10/box |
each | $295.00 | |
| ACLA-SS-10 | k:58N/m;f:190kHz;Super sharp tip (1-2 nm)- Tapping?/Non-contact mode in air, Al on reflex side, Si probe;10/box |
each | $672.00 | |
| HART0-1-5 | k:40N/m;f:300kHz;High aspect ratio tip- 1 渭m long spike- 0掳 tilt compensation, Uncoated, Si probe;5/box |
each | $1,050.00 | |
| STEP-OX-0.1 | 100nm,SiO2 Step Height Reference |
each | $365.00 | |
| STEP-OX-0.1-D | 100nm,SiO2 Step Height Reference, mounted on Metal Disc |
each | $385.00 |
AFM accessories-Budgetsensors-AFM tips
There are lots of AFM probes，such as Standard Tapping Mode AFM Probes，Soft Tapping Mode AFM Probes，Force Modulation AFM Probes,Contact Mode AFM Probes,Gold Coated AFM Probes,Conductive AFM Probes,Magnetic AFM Probes,High Resolution AFM Probes,Diamond and DLC Coated AFM Probes,All-In-One AFM Probes,Tipless AFM Probes,BudgetComboBox,
| Product# | Description | Unit | Price | Qty / Quote |
|---|---|---|---|---|
| AIODLC-10 | k值：0.2N/m(CB1) 、2.7N/m(CB2)、7.4N/m(CB3)、40N/m(CB4)，f值：15kHz(CB1)、80kHz(CB2)、150kHz(CB3)、350kHz(CB4),Coating: Hard Diamond-Like-Carbon ，AFM tip shape: Rotated，10/box |
each | $299.25 | |
| AIOAl-TL-10 | k值：0.2N/m(CB1) 、2.7N/m(CB2)、7.4N/m(CB3)、40N/m(CB4)，f值：15kHz(CB1)、80kHz(CB2)、150kHz(CB3)、350kHz(CB4),Coating: Reflective Aluminum ，AFM tip shape: Tipless，10/box |
each | $247.00 | |
| AIO-DD-10 | k值：0.5N/m(CB1) 、6.5N/m(CB2)、18N/m(CB3)、100N/m(CB4)，f值：19kHz(CB1)、110kHz(CB2)、200kHz(CB3)、450kHz(CB4),Coating: Conductive Diamond ，AFM tip shape: Rotated，10/box |
each | $1,282.50 | |
| Tap300E-G-10 | k值：40N/m ，f值：300kHz,Coating: Electrically Conductive ，AFM tip shape: Rotated，10/box |
each | $228.00 | |
| Multi75E-G-10 | k值：3N/m ，f值：75kHz,Coating: Electrically Conductive， AFM tip shape: Rotated，10/box |
each | $228.00 | |
| Tap190DLC-10 | k值：48N/m ，f值：190kHz,Coating: Hard Diamond-Like-Carbon ，AFM tip shape: Rotated，10/box |
each | $285.00 | |
| Multi75DLC-10 | k值：3N/m ，f值：75kHz,Coating: Hard Diamond-Like-Carbon ，AFM tip shape: Rotated，10/box |
each | $285.00 | |
| AIO-TL-10 | k值：0.2N/m(CB1) 、2.7N/m(CB2)、7.4N/m(CB3)、40N/m(CB4)，f值：15kHz(CB1)、80kHz(CB2)、150kHz(CB3)、350kHz(CB4),Coating: none，AFM tip shape: Tipless，10/box |
each | $247.00 | |
| Tap190GD-G-50 | k值：48N/m ，f值：190kHz,Coating: Reflective Gold ，AFM tip shape: Rotated，50/box |
each | $1,026.00 | |
| SHR150-5 | k值：5N/m ，f值：150kHz,Coating: Reflective Gold ,AFM tip shape: Supersharp,5/box |
each | $460.75 |
AFM accessories-Nanosensors-AFM tips
AFM Probes - Listed by Measuring Mode or Application:Non-Contact (NC) / Tapping / AC Mode AFM Probes,Force Modulation Mode (FM) AFM Probes,Contact Mode (Cont) AFM Probes,Enhanced Resolution Imaging AFM Probes, etc
| Product# | Description | Unit | Price | Qty / Quote |
|---|---|---|---|---|
| ATEC-CONT-10 | k: 0.2N/m; f: 15kHz; Contact Mode AFM Probe with REAL Tip Visibility; Coating: none; AFM tip shape: Visible; 10/box |
each | $422.75 | |
| ATEC-CONTAu-10 | k: 0.2N/m; f: 15kHz; Gold Coated Contact Mode AFM Probe with REAL Tip Visibility; Coating: none; AFM tip shape: Visible; 10/box |
each | $845.50 | |
| ATEC-CONTPt-10 | k: 0.2N/m; f: 15kHz; Electrical, Contact Mode AFM Probe with REAL Tip Visibility; Coating: Electrically Conductive; AFM tip shape: Visible; 10/box |
each | $845.50 | |
| each | $0.00 | |||
| ATEC-NCPt-10 | k: 45N/m; f: 335kHz; Electrical, Tapping Mode AFM Probe with REAL Tip Visibility; Coating: Electrically Conductive; AFM tip shape: Visible; 10/box |
each | $845.50 | |
| ATEC-FM-10 | k: 2.8N/m; f: 85kHz; Force Modulation AFM Probe with REAL Tip Visibility; Coating: none; AFM tip shape: Visible; 10/box |
each | $422.75 | |
| AR10-NCHR-10 | k:42 N/m,f:320 kHz,Detector Side Coating:Reflex (Al),High Aspect Ratio Tip (10:1),10/box |
each | $1,505.75 | |
| AR5-NCH-10 | k: 42N/m; f: 330kHz; High-Aspect-Ratio, Tapping Mode AFM Probe; Coating: none; AFM tip shape: High-Aspect-Ratio; 10/box |
each | $1,003.20 | |
| PtSi-CONT-10 | k: 0.2N/m, f: 13kHz; Electrical, Contact Mode AFM Probes; Coating: Platinum Silicide Overall; AFM tip shape: Standard; 10/box |
each | $1,671.05 | |
| SSS-NCH-10 | k:42 N/m,f:320 kHz,SuperSharpSilicon™ tip,10/box |
each | $760.00 |
AFM accessories-Nanoworld-AFM tips
Pointprobe® silicon AFM probes are most widely used and best-known AFM probe world-wide，Ultra-Short Cantilevers (USC) are for Fast-/High-Speed AFM，Arrow™ Silicon AFM Probes are Optimized positioning through maximized tip visibility，Pyrex-Nitride AFM Probes are Leading edge in AFM tip sharpness and durability。
| Product# | Description | Unit | Price | Qty / Quote |
|---|---|---|---|---|
| Arrow™ CONT-10 | k:0.2 N/m,f:14kHz,10/box |
each | $313.50 | |
| Arrow™ FM-10 | k:2.8 N/m,f:75kHz,10/box |
each | $313.50 | |
| CONT-50 | k:0.2 N/m,f:13 kHz,Standard tip shape,30/box |
each | $1,257.80 | |
| CONTSC-10 | k:0.2 N/m,f:25 kHz,Short cantilever,10/box |
each | $318.25 | |
| ZEILR-10 | k:1.6 N/m,f:27 kHz,Detector Side Coating:Reflex (Al),Standard tip shape,10/box |
each | $318.25 | |
| SEIHR-10 | k:15N/m,f:130kHz,Detector Side Coating:Reflex (Al),Standard tip shape,10/box |
each | $318.25 | |
| CDT-FMR-10 | k:6.2 N/m,f:105 kHz,Tip Side Coating：Conductive diamond，Detector Side Coating：Reflex (Al)，Conductive diamond coated tip,10/box |
each | $1,671.05 | |
| S-MFMR-10 | k:2.8N/m,f:75kHz,Tip Side Coating:Soft magnetic, medium momentum,Detector Side Coating:Reflex (Al),Standard tip shape,10/box |
each | $540.55 | |
| PNP-DB-20 | k值：0.48N/m（CB1)、 0.06 N/m (CB2)，f值：67 kHz（CB1）、17 kHz（CB2），Detector Side Coating：Reflex (Au)，Cantilever(s) Shape：Beam,20/box |
each | $480.70 | |
| USC-F5-k30-10 | k:30N/m,f:5000kHz,Coating：Reflex (Au)，10/box |
each | $931.00 |
